IRL5111FI

Resolution (Bits) 12

Sample rate (max) (ksps) 500

Number of input channels 8

Interface type SPI

Architecture SAR

Input type Single-ended, differential

Reference mode External, Internal

DNL (LSB) ±0.2

INL (LSB) ±0.75

SNR (dB) 72.5

SFDR (dB) -80

Supply current (mA/per channel) 1

Analog supply voltage (typ) (V) 5

Digital supply (min) (V) 1.62

Digital supply (max) (V) 5

Operating temperature range (°C): -40 to 85

Applications Temperature (NTC/PTC, thermocouple, RDT) measurements, pressure/position/current (shunts, sensors)/consumption measurements, Data Acquisition Systems (DAQ), Battery management Systems, Industrial process control.

Package QFN

Pins 48

Size (mm) 7х7х0,75

12-Bit ADC with integrated analog front-end
8-channel MUX with auto and manual scan
500-kSPS aggregate throughput
Channel-independent programmable inputs: (±) 10.24 V, … (±) 0.64 V and 10.24 V, 5.12 V, 2.56 V, 1.28V, 0.64 V (differential mode only)
Processing of single-ended and differential input signals
Constant Resistive Input Impedance over 1 MΩ
Input overvoltage protection up to ± 20 V
On-chip, 4.096 V reference with low drift
On-chip oscillator
SPI compatible interface with Daisy-Chain
ALARM with High and Low Thresholds per Channel
AUX Input – Direct Connection to ADC Inputs

The IRL5111FI is a 12-bit data acquisition system with 8-channel analog inputs. Each analog input channel consists of an overvoltage protection circuit, a multiplexer with automatic or manual scanning. The device features a 4.096-V internal reference and operates from a single 5-V analogue supply. Each channel can be individually programmed for processing bipolar input ranges (± 0.64V; ±10.24V) in single-ended or differential modes or unipolar ranges from 0 to 1.28-10.24V single-ended or from 0 to 0.64-10.24 V differential.
